| GPU |
AMD Radeon RX 7600 Graphics Card |
| Architecture |
AMD RDNA 3 Architecture |
| Engine Clock |
Boost Clock: Up to 2755 MHz |
|
Game Clock: Up to 2355 MHz |
| Stream Processors |
2048 |
| Compute Units |
32 CU |
| Infinity Cache |
32MB |
| Ray Accelerators |
32 |
| Memory Size/Bus |
8GB/128 bit GDDR6 |
| Memory Clock |
18 Gbps Effective |
| Displays |
Maximum 4 Displays |
| Resolution |
HDMI: 7680×4320 |
|
DisplayPort 1.4: 7680◊4320 |
| Interface |
PCI-Express 4.0 x8 |
| Output |
1x HDMI |
|
3x DisplayPort |
| BIOS Support |
UEFI |
| Game Index |
1080P Ultimate |
| Sapphire Features |
Fuse Protection |
|
Dual-X Cooling Technology |
|
Intelligent Fan Control |
|
Precision Fan Control |
|
Metal Backplate |
|
Two-Ball Bearing Fans |
|
Optimized Composite Heatpipe |
|
TriXX Supported |
|
TriXX Boost |
| AMD Features |
AMD RDNA 3 Architecture |
|
DirectX 12 Ultimate |
|
AMD Smart Access Memory |
|
AMD Infinity Cache |
|
PCI Express 4.0 Support |
|
AMD FreeSync Technology |
|
DisplayPort 1.4 with DSC |
|
HDMI |
|
Video Streaming up to 8K |
|
AMD Radeon VR Ready Premium |
|
AMD Radeon Image Sharpening |
|
AMD Radeon Anti-Lag |
|
AMD Software: Adrenalin Edition Technology |
|
Game Driver Optimizations |
| Cooling |
2 Fans |
| Form Factor |
2 slot, ATX |
| Dimension |
240(L)X 107.1(W)X 44.07 (H)mm |
| Power Consumption |
185W Total Board Power |
| OS |
Linux, Windows 10, and Windows 11 |
|
64-bit operating system required |
| System Requirement |
Minimum 550 Watt Power Supply |
|
1 x 8-pin Power Connector |
|
PCI Express based PC is required with one X16 lane |
|
graphics slot available on the motherboard |
|
Minimum 8GB of system memory. 16GB recommended. |
| Warranty |
3 Years |
