Description
- Camera
- Image Sensor3K CMOS
- Signal SystemPAL/NTSC
- Max. Resolution2960 (H) × 1665 (V)
- Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night24/7 Color Imaging
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360°
- Lens
- Lens Type2.8 mm, 3.6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°
3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96°
- Lens MountM12
- Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 20 m
- Image
- Frame Rate
TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps
AHD: 5 MP@20fps, 4 MP@25fps/30fps
CVI: 4 MP@25fps/30fps
CVBS: PAL/NTSC
- Wide Dynamic Range (WDR)Digital WDR
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
- Day/Night ModeColor
- White BalanceAuto/Outdoor/Global/Manual
- Image EnhancementDWDR, BLC, HLC, Global, HLS
- Noise Reduction2D DNR
- Image SettingsBrightness, Contrast, Mirror, Defective Pixel Correction, Sharpness, Anti-Banding, Smart Light, AGC
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- AlarmSolid Light Alarm (White Light)
- AudioBuilt-in mic
- General
- LanguageEnglish
- Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- MaterialPlastic
- CommunicationHIKVISION-C
- DimensionΦ 85.02 mm × 81.25 mm (Φ 3.35″ × 3.2″)
- Approx. 165.5 g (0.36 lb.)
- Power
12 VDC ± 25%, Max. 2.5 W,
*You are recommended to use one power adapter to supply the power for one camera.
